I’m interested in using a Boss FS-7 pedal instead of their original pedal. Can anyone tell me if this works or if I should order their original pedal?
Many thanks!!
Yes, the Boss FS-7 works perfectly with the BeatBuddy, as long as you use a TRS (stereo) cable and set everything up properly in the BeatBuddy settings.
Key things to know:
- The Boss FS-7 is a dual footswitch with a single TRS output, just like the Singular Sound Footswitch+.
- It supports momentary or latching operation. You must use it in “momentary” mode for the BeatBuddy to work correctly.
- The mode is selected via the small toggle switches on the back of the FS-7. Set both channels (A and B) to the “A” position (momentary normally open).
How to set it up with the BeatBuddy:
- Connect the FS-7 to the BeatBuddy’s Footswitch input using a TRS (stereo) 1/4" cable.
- Power on the BeatBuddy.
- Go to:
- Main Menu > Footswitch > Footswitch Detector
- Press each FS-7 switch once when prompted, so the BeatBuddy can detect the input type.
- Then go to:
- Main Menu > Footswitch > Footswitch Settings
- Assign functions to each button (e.g. accent hit, pause/unpause, next part, etc.)
Notes:
- The FS-7 is more compact than the official footswitch, which can be a big plus on smaller pedalboards.
- It features soft-touch switches — they don’t click, so they’re quieter than traditional switches.
Summary Table:
| FS-7 with BeatBuddy | Works? | Notes |
|---|---|---|
| TRS connection |  Yes |
Required |
| Momentary mode | Yes |
Must be set on the FS-7 |
| Function assignment | Yes |
Fully customizable in BeatBuddy menu |
2 Likes
Confirmed - The BeatBuddy is compatible with standard momentary or latching dual
footswitches which have a single TRS (Stereo) ¼” output (one switch is connected to
the Left channel and the other to the Right).
Thank you very much for taking the time to provide such a detailed answer!!
1 Like
EDIT: CORRECTION TO COMMENT BELOW AND USEFUL INFO ON THE BOSS FS-7 PEDAL
The Boss FS-7 Pedal WILL WORK if the AC-Adapter is connected (it worked without that on BB1), and the Polarity is on choice II, and button type is “momentary”. So, if you don’t mind hauling around another power block or using pedal power, you can use your Boss FS-7.
ORIGINAL COMMENT:
However, if you are going to use FS-7 on Beatbuddy 2…it does NOT work without the caveats mentioned above. As I have just spent this whole morning trying to get it to detect on BB2…it does work great on BB1 though.
Hi Scott,
Thank you for reporting the issue! I’ve forwarded it to the team!
